Retrofit Gear Trays – Custom/Bespoke

Products Retrofit Gear Trays – Custom/Bespoke

Product Details

Economical upgrade of exisiting luminaires with ease with our bespoke LED Retrofit gear tray options. Custom made to bespoke sizes, lumen packages, colour temperatures, dimming options & emergency options, the retrofit gear trays can be manufactured in a varierty of options to suit almost every applicaton, from wall pack, in-ground light to bulkhead & linear luminaries.

Designed to be installed directly into exisiting luminaries with ease & minimal modifications, saving on time, labour and cost as removes the need for expensive re-wiring and re-running of cables, as well as reduced waste which is typically minimised to just an existing lamp. Further benefits include minimised burden of long-term
maintenance & ensure seriviceability of luminaire.

Additional options of dimmable: DALI (-DL) / 1-10V (-AD) / DSI (-DSI), as well as built-in microwave sensor (-MI) for occupancy detection, or external mount PIR sensor for occupancy detection and daylight dimming (-PIR) functionality. 3-hour emergency version also available with self-test (-EM) or auto-test (-AEM) and LED
status indicator light.

Product information

Durable with a rated life span of +45,000 hours / No UV or IR emissions / Instant on & Flicker free / CE & RoHS international standards / Environmentally friendly & part recyclable: no mercury or other hazardous materials used / 1050 aluminium alloy PCB / Optional PMMA optical lens if required / Tridonic® cable feed / Custom fixing points for quick installation & secure fixing / Optional emergency kit / Optional PIR/microwave sensor.

Product Specification

Beam Angle


Luminous Efficacy

Up to 140lm/W

Input Voltage

AC 100-280V

High Colour Rendering Index

≥ 80Ra

LED Type

As per request

Operating Temperature

-20°C to 50°C

Colour Temperature

Bespoke / Custom

Product Gallery
