LED Recessed canopy luminaire designed specifically industrial & exterior recessed ceiling canopies such as fuel stations, industrial clean-room applications and others. Finished in a rugged RAL White powder coated aluminium housing with tempered, stabilised, impact resistant PMMA lens, the recessed canopy luminaire is suitable for extreme climates & environments from -20˚C to +50˚C.
A range of lumen packages from 60W – 150W, up to 16,500lm hence suitable for mount heights up to 12m – making a suitable direct replacement for 400W SON fittings. Energy-efficiency, low luminous decay and maintenance were key factors in the luminaire design, meaning annual re-lamp, expensive lift equipment and inconvenience is negligible, as well as a much sought after energy savings of 75%.
Further enhancments include high efficiency Meanwell™ HLG series driver the the heart of the luminaire, whilst further options of dimmable: DALI (-DL) / 1-10V (-AD).
Product information
Durable with rated life span of +50,000 hours / No UV or IR emissions / Instant on & Flicker free / CE & RoHS international standards / Environmentally friendly & part recyclable: no mercury or other hazardous materials used / 6063 Silver Anodised Aluminium heat sink & PMMA optics / 1m suspension kit (SDAIS-XXX-SUSP) / Meanwell™ HLG Driver
Product Specification
|
Beam Angle |
90˚ x 90˚ (Others on request) |
|
Luminous Efficacy |
Up to 110lm/W |
|
Input Voltage |
AC 110-280V |
|
High Colour Rendering Index |
≥ 80Ra |
|
LED Type |
Epistar® SMD3030 LED |
|
Operating Temperature |
-20°C to 50°C* |
|
Power Factor |
≥ 0.95 |
